2002 2003 Nevada Base club 750 Frame Rear Footrests
| Position | Part Number | Description |
|---|---|---|
| 1 | 31446083 | #01 LH footrest support (#31446083) |
| 2 | 31443583 | #02 RH foot rest support (#31443583) |
| 3 | ||
| 4 | 98682420 | Screw (#98682420) |
| 5 | 29436450 | BUSHING (#29436450) |
| 6 | 66441730 | PLATE (#66441730) |
| 7 | 23943410 | CHROME PLUG (#23943410) |
| 8 | 95008308 | Washer (#95008308) |
| 9 | 92640508 | Nut (#92640508) |
| 10 | 98257830 | Screw (#98257830) |
| 11 | 90280006 | E CLIP (#90280006) USE 005965 |
| 12 | 66440630 | PIN (#66440630) |
| 13 | 66440730 | RH front foot rest pipe (#66440730) |
| 14 | 66441830 | LH Foot Rest Arm (#66441830) |
| 15 | 66441630 | Special Washer (#66441630) |
| 16 | 51609800 | SPRING WASHER (#51609800) |
| 17 | 66443230 | Rear Foot Peg (#66443230) |
| 18 | 31441283 | Plate (#31441283) |
| 19 | 98304012 | Screw (#98304012) |
| 20 | 93180206 | RUBBER PLUG (#93180206) |
