2002 California Special Sport al. PL 1100 Frame Cradle Arm Foot Rests
| Position | Part Number | Description |
|---|---|---|
| - | 3443565 | #05 RH Plate grey (#3443565) |
| - | 3446065 | #07 LH Plate grey (#3446065) |
| - | 3446965 | #03 RH cover chromium grey (#3446965) |
| - | 3447465 | #04 LH cover grey (#3447465) |
| 1 | 3420331 | #01 RH craddle arm (#3420331) |
| 2 | 3422130 | #02 LH craddle arm (#3422130) |
| 3 | 3446930 | #03 RH cover chromium plated (#3446930) |
| 4 | 3447450 | #04 LH cover chromium plated (#3447450) |
| 5 | 98370621 | BOLT (#98370621) |
| 6 | 95008208 | WASHER (#95008208) |
| 7 | 93231606 | RUBBER BUSHING (#93231606) |
| 8 | 3443930 | #08 Support (#3443930) |
| 9 | 3611445 | #08 Screw w/ flange M8x20 (#3611445) |
| 10 | 3270300 | #26 Washer 8,4x15 (#3270300) |
| 11 | 3444230 | #11 Spacer (#3444230) |
| 12 | 3429500 | #12 Pin (#3429500) |
| 13 | 95008313 | Washer, 13X24X2.5 (#95008313) |
| 14 | 92606512 | Low Nut (#92606512) |
| 15 | 29443550 | MOUNT (#29443550) |
| 16 | 23440710 | RF FOOTPEG A (#23440710) |
| 17 | 29446050 | L H PLATE (#29446050) |
| 18 | 23441810 | LF FOOTPEG A (#23441810) |
| 19 | 23443210 | FOOTREST RUBBER (#23443210) |
| 20 | 23441210 | FOOTREST PLATE (#23441210) |
| 21 | 98084314 | BOLT (#98084314) |
| 22 | ||
| 23 | 91180602 | SPACER (#91180602) |
| 24 | 3442200 | #14 Screw (#3442200) |
| 25 | 98370614 | Screw (#98370614) |
| 26 | 92640508 | Nut (#92640508) |
| 27 | 98683635 | Screw 12X35 (#98683635) |
| 28 | 98681650 | Screw (#98681650) |
| 29 | 17444250 | SPACER (#17444250) |
| 30 | 95100414 | WASHER (#95100414) |
| 31 | 95022112 | Washer (#95022112) |
| 33 | 92606312 | Nut (#92606312) |
| 34 | 98683640 | Screw 12X40 (#98683640) |
| 35 | 93180245 | RUBBER PLUG (#93180245) |
| 36 | 95005306 | WASHER (#95005306) |
| 37 | 30425260 | CROSS BRACE A (#30425260) |
| 38 | 98350522 | Bolt, Cradle Strap (#98350522) |
| 39 | 95022110 | Washer (#95022110) |
| 40 | 823931055 | MOULDING (#823931055) |
| 41 | 3440730 | #41 RH front foot rest pipe (#3440730) |
| 42 | 3441830 | LH front foot rest pipe (#3441830) USE 03441830 |
| 43 | 3443730 | #43 Support (#3443730) |
| 44 | 23442210 | PIVOT PIN A (#23442210) |
| 45 | 95401215 | COTTER PIN (#95401215) |
| 46 | 3441130 | #20 Spring (#3441130) |
| 47 | 95100250 | SHIM (#95100250) |
| 48 | 95129130 | SHAKE PROOF WASHER (#95129130) |
| 49 | 98350450 | BOLT (#98350450) |
| 50 | 92630708 | NUT A (#92630708) |
