| Position |
Part Number |
Description |
| - |
| - |
2762400
|
#01 Speedometer MPH Borletti (#2762400) |
| - |
2764000
|
#12 Dashboard lower support (#2764000) |
| - |
| - |
| - |
| - |
| - |
| - |
3761570
|
Speedometer AUSEUJNZ (#3761570) USE 03761570 |
| - |
3761970
|
#15 Tachometer support (#3761970) |
| - |
3762070
|
#14 Odometer support (#3762070) |
| - |
3762470
|
#01 Speedometer UKUSA (#3762470) |
| - |
3762550
|
Odometer gear (#3762550) USE 03762550 |
| - |
3766265
|
#26 Lamp-holding cover gray (#3766265) |
| - |
3767270
|
#09 Electronic revolution counter (#3767270) |
| - |
92660007
|
NUT(#92660007) |
| - |
92787205
|
NUT (#92787205) |
| - |
95008304
|
Washer (#95008304) |
| - |
98370609
|
BOLT (#98370609) |
| - |
98872120
|
ALLEN BOLT (#98872120) |
| 1 |
2761500
|
#01 Speedometer KMH Borletti (#2761500) |
| 2 |
23768310
|
ANGLE DRIVE (#23768310) |
| 3 |
2762800
|
Reset button (#2762800) USE 02762800 |
| 4 |
1760400
|
USE 01760400 (#1760400) |
| 5 |
28762540
|
SPEEDO DRIVE ASSY. (#28762540) |
| 6 |
1782500
|
#06 Main switch steering lock (#1782500) |
| 7 |
2768600
|
#07 Lampholder (#2768600) USE 02768600 |
| 8 |
93450120
|
BULB ALL GLASS (#93450120) |
| 9 |
2767200
|
#09 Electronic revolution counter (#2767200) |
| 10 |
1763030
|
#10 Spacer (#1763030) |
| 11 |
95100055
|
WASHER (#95100055) |
| 12 |
3764060
|
#12 Dashboard lower support (#3764060) |
| 13 |
2762301
|
Support rubber part (#2762301) use 02762301 |
| 14 |
| 15 |
92787105
|
#15 Cap nut (#92787105) |
| 16 |
17762200
|
RUBBER BOOT (#17762200) |
| 17 |
30735500
|
IGNITION KEY BLANK (#30735500) |
| 18 |
1766031
|
#18 Socket support (#1766031) |
| 19 |
93222023
|
Silent - Block (#93222023) |
| 20 |
93400012
|
Lamp Holder End (#93400012) |
| 21 |
98350310
|
Screw (#98350310) |
| 22 |
3747200
|
#02 Dashboard cable Borletti (#3747200) |
| 23 |
92650136
|
CLUTCH MOUNT NUT (#92650136) |
| 24 |
98692318
|
ALLEN SCREW (#98692318) |
| 25 |
95008306
|
WASHER (#95008306) |
| 26 |
1766240
|
#26 Lampholding cover black (#1766240) |
| 27 |
98872115
|
ALLEN BOLT (#98872115) |
| 28 |
2768200
|
#28 Gasket (#2768200) |
| 29 |
2768400
|
#29 Protection (#2768400) |
| 30 |
| 31 |
| 32 |
30577800
|
NYLON WASHER (#30577800) |
| 33 |
97260415
|
SECURITY BOLT A (#97260415) |
| 34 |
93450140
|
BULB (93450140) (#93450140) USE 164634 |
| 35 |
2761900
|
#14 Tachometer support (#2761900) |
| 36 |
2762000
|
#15 Odometer support (#2762000) |
| 37 |
| 38 |
91551168
|
Button Seal (#91551168) |
| 39 |
3762370
|
#10 Gasket (#3762370) USE 03762370 |
