2002 California Special Sport al. PL 1100 Frame Exhaust Unit
| Position | Part Number | Description |
|---|---|---|
| - | ||
| - | ||
| 1 | 3120960 | #01 RH exhaust pipe (#3120960) |
| 2 | 3120961 | #02 LH exhaust pipe (#3120961) |
| 3 | 90718370 | EXHAUST GASKET (#90718370) |
| 4 | 3128601 | #11 RH/LH plate (#3128601) |
| 5 | 1121030 | #07 Flange (#1121030) |
| 6 | 14615901 | WASHER (#14615901) |
| 7 | 92787008 | NUT (#92787008) USE 860651 |
| 8 | 3123900 | #08 Expansion chamber (#3123900) |
| 9 | 30123430 | EXHAUST CLAMP (#30123430) |
| 10 | 3123000 | #10 RH silencer, chromium plated (#3123000) |
| 11 | 3128600 | #11 RH plate (#03128600) |
| 12 | 95008208 | WASHER (#95008208) |
| 13 | 92640508 | Nut (#92640508) |
| 14 | 95005311 | WASHER (#95005311) |
| 15 | 3122900 | #15 LH silencer, chromium plated (#3122900) |
| 16 | 3128700 | #16 LH plate (#03128700) |
| 17 | 3123400 | #17 Hose clamp (#3123400) |
| 18 | 98084425 | Bolt 8mmx25mm (#98084425) |
| 19 | 3270300 | #26 Washer 8,4x15 (#3270300) |
| 20 | 98110007 | PLUG (#98110007) |
| 21 | 30109330 | COPPER WASHER (#30109330) |
| 22 | 3121230 | #22 Half-cone (#3121230) |
| 23 |
