2002 California Special Sport al. PL 1100 Frame F Fork R Shock Absorber
| Position | Part Number | Description |
|---|---|---|
| 1 | ||
| 2 | 30513401 | NUT (#30513401) |
| 3 | 30516500 | WASHER (#30516500) |
| 4 | 14516700 | SHIM (#14516700) |
| 5 | 14517000 | RING DUST SEAL (#14517000) |
| 6 | 92249225 | TAPERED ROLLER BRNG (#92249225) |
| 7 | ||
| 8 | 3531000 | #08 Plate (#3531000) |
| 9 | ||
| 10 | 98084325 | Hex screw (#98084325) |
| 11 | 95008306 | WASHER (#95008306) |
| 12 | 92630707 | NUT (#92630707) |
| 13 | 98350320 | SCREW (#98350320) |
| 14 | ||
| 15 | 3550260 | Shock absorber Sachs(3550260) USE 03550261 (#3550260) |
| 16 | 3541850 | Swing Arm Pin (#3541850)USE 03541850 |
| 17 | 95100432 | Washer (#95100432) |
| 18 | 95100141 | WASHER (#95100141) |
| 19 | 98370614 | Screw (#98370614) |
| 20 | 3270300 | #26 Washer 8,4x15 (#3270300) |
| 21 | 1517700 | #21 Decal Aquilia (#1517700) |
