2002 California Special Sport al. PL 1100 Frame Rear Lights
| Position | Part Number | Description |
|---|---|---|
| - | 3475860 | Headlight holder black (#3475860) USE 03475860 |
| - | ||
| - | ||
| 1 | ||
| 2 | 3475931 | #02 Support rubber part (#3475931) |
| 3 | ||
| 4 | 98682320 | Screw (#98682320) |
| 5 | 95001206 | WASHER (#95001206) |
| 6 | 92660600 | CAGE NUT (#92660600) |
| 7 | 3751631 | #07 RH front/LH rear turn indic. (#3751631) |
| 8 | 93450127 | T/SIG. BULB - CLEAR (#93450127) |
| 9 | 31753765 | SIGNAL LENS AMBER (#31753765) USE AP8124111 |
| 10 | ||
| 11 | 98620150 | SCREW (#98620150) |
| 12 | 93450224 | BULB T.L. (#93450224) |
| 13 | 3741230 | BUSHING (#3741230) USE 03741230 |
| 14 | 93231604 | WELL NUT (#93231604) |
| 15 | 3742030 | #15 Bush (#3742030) |
| 16 | ||
| 17 | 95008205 | Washer 5.3mm (#95008205) |
| 18 | 1474630 | #10 Number plate holder (#1474630) |
| 19 | 3474530 | #19 Number plate holder support (#3474530) |
| 20 | 98370515 | ALLEN SCREW (#98370515) |
| 21 | 93110060 | RUBBER WASHER (#93110060) |
| 22 | 92650035 | Nut (#92650035) |
| 23 | 3438830 | #23 Plug (#3438830) |
| 24 | 3438831 | #24 Plug (#3438831) |
| 25 | 3475330 | #25 Support (#3475330) |
| 26 | 31745865 | REFLECTOR RED A (#31745865) |
| 27 | 92650034 | Nut (#92650034) |
| 28 | ||
| 29 | 14781570 | REFLECTOR (#14781570) |
| 30 | 14781870 | BRACKET (#14781870) |
