2002 California Special Sport al. PL 1100 Frame Rear Wheel
| Position | Part Number | Description |
|---|---|---|
| - | 12616102 | BALANCE WEIGHT 20 GRAMS (28 GRAMS=1 OZ) (#12616102) |
| - | 12616103 | BALANCE WEIGHT (#12616103) |
| 1 | 3630650 | #01 Rear wheel 3,50x17 inch (#3630650) |
| 2 | 14615901 | WASHER (#14615901) |
| 3 | 92204220 | BEARING (#92204220) |
| 4 | 14634051 | SPACER (#14634051) |
| 5 | 30631160 | SPOKE SHORT (#30631160) |
| 6 | 12616101 | BALANCE WEIGHT (#12616101) |
| 7 | 30631430 | SPOKE, LONG (#30631430) |
| 8 | 3611740 | #08 Nipple (#3611740) |
| 9 | ||
| 10 | 30611460 | ALLEN BOLT (#30611460) |
| 11 | 3633350 | #11 Rear wheel spindle (#3633350) |
| 12 | ||
| 13 | 90706490 | O RING (#90706490) |
| 14 | 30335260 | DISC-CUSH DRIVE B (#30335260) |
| 15 | 14335303 | RING (#14335303) |
| 16 | 17335950 | LOCK PLATE (#17335950) |
| 17 | ||
| 18 | 98084312 | BOLT, rear drive snap ring (#98084312) |
| 19 | 3634150 | #19 Spacer (#3634150) |
| 20 | 95008219 | Washer (#95008219) |
| 21 | 92630718 | AXLE NUT (#92630718) |
| 22 | 3632440 | #22 Plate holder hub (#3632440) |
| 23 | 90272047 | CIRCLIP (#90272047) |
| 24 | 17633550 | CUP (#17633550) |
| 25 | 98822430 | BOLT (#98822430) |
| 26 | 3630740 | #26 Rear wheel 3,50x17 inch (#3630740) |
| 27 | 90271055 | CIRCLIP (#90271055) |
