2002 V 11 Le Mans 1100 Crankshaft Cpl
| Position | Part Number | Description |
|---|---|---|
| 1 | 1060190 | Cylinder with piston (#1060190) |
| 2 | 01060231 | Piston assy (#01060231) |
| 3 | 30060660 | PISTON RING SET #30060660) (#30060660) |
| 4 | 30060760 | PISTON RING TOP (#30060760) |
| 5 | 30060960 | PISTON RING 2ND (#30060960) |
| 6 | 30061060 | PISTON RING 3RD (#30061060) |
| 7 | 30061241 | WRIST PIN (#30061241) |
| 8 | 90351038 | CIRCLIP (#90351038) |
| 9 | 14020865 | BASE GASKET (#14020865) |
| 10 | 90706094 | O RING-VITON (#90706094) |
| 11 | 12021800 | BOLT (#12021800) |
| 12 | 12021700 | BOLT-ROD (#12021700) |
| 13 | 01061532 | Connecting Rod (#01061532) |
| 14 | 01062230 | Bolt, Conrod (#01062230) |
| 15 | 91112128 | BUSH-CON ROD (#91112128) |
| 16 | 01062030 | Bearing, Half (#01062030) |
| 16 | 01062031 | Bearing half-shell min.0,254 (#01062031) |
| 16 | 01062032 | Bearing half-shell min.0,508 (#01062032) |
| 16 | 01062033 | Bearing half-shell min.0,762 (#01062033) |
| 17 | 01064131 | Crankshaft, V11 (#01064131) |
| 18 | 37065405 | CRANK PLUG (#37065405) |
| 19 | 04067000 | FLYWHEEL (#04067000) |
| 20 | 12067701 | SCREW (#12067701) use 597150 |
| 21 | 14615901 | WASHER (#14615901) |
| 22 | 01067930 | RING GEAR (#01067930) |
| 23 | 37067705 | ALLEN BOLT (#37067705) USE 122675 |
| 24 | 14217901 | LOCK WASHER (#14217901) USE AP8152105 |
