| Position |
Part Number |
Description |
| 1 |
01577260
|
V11 LEMANS SHIELD (#01577260) |
| 2 |
01575490
|
LH Fairing, Blank (#01575490) |
| 2 |
01575491
|
COWLING LH BLACK (#01575491) |
| 2 |
01575492
|
COWLING LH RED (#01575492) |
| 2 |
01575493
|
LH Fairing Red (#01575493) |
| 2 |
01575494
|
LH Fairing Nero Corsa (#01575494) |
| 3 |
01575760
|
Fairing, Lower center, Blank (#01575760) |
| 3 |
01575765
|
Front Cowling, Lower Black (#01575765) |
| 3 |
01575766
|
Front Cowling, Lower Red (#01575766) |
| 3 |
01575790
|
Fairing Lower Center Red (#01575790) |
| 3 |
01575791
|
Fairing Lower Center Black (#01575791) |
| 4 |
01575590
|
LH Fairing, Blank (#01575590) |
| 4 |
01575591
|
COWLING RH BLACK (#01575591) |
| 4 |
01575592
|
RH FAIRING (#01575592) |
| 4 |
01575593
|
RH Fairing Red (#01575593) |
| 4 |
01575594
|
RH Fairing Nero Corsa (#01575594) |
| 5 |
01575662
|
Fairing, Upper center, Blank (#01575662) |
| 5 |
01575665
|
FRT COWLING UPPER BLACK (#01575665) |
| 5 |
01575666
|
Front Cowling, Upper Red (#01575666) |
| 5 |
01575690
|
Fairing Support Center Red (#01575690) |
| 5 |
01575691
|
Fairing Support Center Black (#01575691) |
| 6 |
01576365
|
AIR INTAKE COVER, LH (#01576365) |
| 6 |
01576366
|
Air Intake, LH Black (#01576366) |
| 6 |
01576391
|
AIR SCOOP LH Nero Corsa (#01576391) |
| 7 |
01574760
|
COVER (#01574760) |
| 8 |
01576265
|
Air Intake, RH Grey (#01576265) |
| 8 |
01576266
|
Air Intake, RH Black (#01576266) |
| 8 |
01576291
|
AIR SCOOP RH Nero Corsa (#01576291) |
| 9 |
01926190
|
Front Fairing Decal Red Ballab (#01926190) |
| 10 |
92630205
|
LOCK NUT (#92630205) |
| 11 |
30577800
|
NYLON WASHER (#30577800) |
| 12 |
30577801
|
NYLON WASHER (#30577801) |
| 13 |
98370515
|
ALLEN SCREW (#98370515) |
| 14 |
92787205
|
NUT (#92787205) |
| 15 |
98370616
|
BOLT (#98370616) |
| 16 |
98230512
|
SCREW (#98230512) USE 831153 |
| 17 |
98370609
|
BOLT (#98370609) |
| 18 |
98890370
|
BOLT (#98890370) |
| 19 |
01588360
|
PLATE (#01588360) |
| 20 |
28576591
|
CLIP (#28576591) |
| 21 |
01571860
|
SPLASH PLATE (#01571860) |
| 22 |
92650135
|
Nut (#92650135) |
| 24 |
23922210
|
FASTENER (#23922210) |
| 25 |
01948192
|
Decal set, RH fairing (#01948192) |
| 25 |
01948193
|
Decal set, RH fairing (#01948193) |
| 26 |
01948392
|
Decal set, Central fairing (#01948392) |
| 26 |
01948393
|
Decal set, Central fairing (#01948393) |
| 27 |
01948292
|
KIT DECALCO CAREN SX LEMANS R (#01948292) |
| 27 |
01948293
|
Decal set, LH fairing (#01948293) |
