2003 2004 V 11 1100 Swing Arm And Rear Shock Absorber
| Position | Part Number | Description |
|---|---|---|
| 1 | 01540230 | SWING ARM (#01540230) |
| 2 | 92218418 | Swing arm pivot bearing Spine frame (#92218418) |
| 3 | 01547060 | PIN (#01547060) |
| 4 | 01547860 | NUT (#01547860) |
| 5 | 01550291 | REAR SHOCK (#01550291) |
| 5 | 02550201 | REAR SHOCK (#02550201) |
| 6 | 98083670 | Screw, 12mmx70mm (#98083670) |
| 7 | 95008213 | Washer, 12.2x20x2 (#95008213) |
| 8 | 92640513 | Nut, 12mmx1.25 (#92640513) |
| 9 | 92640512 | Nut, 12mmx1.75 (#92640512) |
| 10 | 98680616 | Screw, Lower (#98680616) |
| 11 | 01557985 | Support plate (#01557985) |
| 12 | 02107300 | CLAMP A (#02107300) |
| 13 | 98210616 | Screw (#98210616) |
| 14 | 92630106 | NUT USE 92630707 (#92630106) |
| 15 | 00823915045 | Rubber spacer (#00823915045) |
| 16 | 30217900 | LOCK WASHER (#30217900) |
