2003 2005 California EV PL Cat. 1100 Engine Generator Regulator
| Position | Part Number | Description |
|---|---|---|
| - | 3747155 | #01 Main wiring harness (#3747155) |
| - | 37712405 | ALTERNATOR (#37712405) |
| 1 | 32712410 | Generator - Breva (#32712410) |
| 2 | 3703870 | #17 Regulator (#3703870) |
| 3 | 30714201 | WASHER (#30714201) |
| 4 | 92606516 | Nut (#92606516) |
| 5 | 29711460 | FRONT COVER (#29711460) |
| 6 | 98680265 | Screw (#98680265) |
| 7 | 29217960 | WASHER (#29217960) |
| 8 | 90706178 | O RING (#90706178) |
| 9 | 37712306 | SPACER (#37712306) |
| 10 | 91600450 | WOODRUFF KEY (#91600450) |
| 11 | 29711960 | REAR COVER (#29711960) |
| 12 | 98692325 | BOLT (#98692325) |
| 13 | 95008306 | WASHER (#95008306) |
| 14 | 28576591 | CLIP (#28576591) |
| 15 | 14217901 | LOCK WASHER (#14217901) USE AP8152105 |
| 16 | 19007700 | RUBBER (#19007700) |
| 17 |
