2003 2005 California EV PL Cat. 1100 Engine Timing System
| Position | Part Number | Description |
|---|---|---|
| - | 3045830 | #02 Tappet closing (#3045830) |
| - | ||
| - | ||
| 1 | 3045030 | #01 Rod (#3045030) |
| 2 | ||
| 3 | 3053330 | #03 Camshaft (#3053330) |
| 4 | 14234600 | PIN (#14234600) |
| 5 | ||
| 6 | 98084320 | Screw (#98084320) |
| 7 | 95120065 | WASHER (#95120065) |
| 8 | ||
| 9 | ||
| 10 | 14433400 | WASHER (#14433400) |
| 11 | 92750180 | Nut (#92750180) |
| 12 | 14072001 | SPROCKET (#14072001) |
| 13 | 95100837 | WASHER (#95100837) |
| 14 | 92602525 | NUT (#92602525) |
| 15 | 91702355 | WOODRUFF KEY (#91702355) |
| 16 | 28058060 | TIMING CHAIN (#28058060) USE 05058030 |
| 17 | 30057810 | CHAIN TENSIONER (#30057810) |
| 18 | 98082435 | BOLT (#98082435) |
| 19 | 14615901 | WASHER (#14615901) |
| 20 | 3048230 | #20 Hydraulic tappet (#3048230) |
| 21 | 3048330 | #21 Calibrated tablet (#3048330) |
