2003 2005 California EV PL Cat. 1100 Frame Front Mudguard
| Position | Part Number | Description |
|---|---|---|
| - | 3434300 | #01 Front mudguard blank (#3434300) |
| - | ||
| - | 3434360 | #01 Front mudguard, black (#3434360) |
| - | ||
| - | ||
| 1 | ||
| 2 | 3435200 | #02 Front RH side profile ch.plate (#3435200) |
| 3 | 3435400 | #03 Front LH side profile ch.plate (#3435400) |
| 4 | 39922200 | PLATE (#39922200) |
| 5 | 3435300 | #05 Rear RH side profile ch.plate (#3435300) |
| 6 | 3435500 | #06 Rear LH side profile ch.plate (#3435500) |
| 7 | 3436400 | Rubber spacer (#3436400) USE 03436400 |
| 8 | 3436500 | #08 Cableguide (#3436500) |
| 9 | 3436300 | #09 Plate (#3436300) |
| 10 | 98082225 | Screw (#98082225) |
| 11 | 92787205 | NUT (#92787205) |
| 12 | 3436600 | #02 Stabilization plate (#3436600) |
| 13 | 98370850 | Screw (#98370850) |
| 14 | 95005308 | WASHER M8 (#95005308) |
| 15 | 98370322 | Hex socket screw M6x22 (#98370322) |
| 16 | 91551010 | GROMMET (#91551010) |
| 17 | 3576170 | #07 Spacer (#3576170) |
