2003 2005 California EV PL Cat. 1100 Timing System
| Position | Part Number | Description |
|---|---|---|
| 1 | 03045030 | Tappet Rod (#03045030) |
| 2 | 03045830 | CLOSINGS EV MOD (#03045830) |
| 2 | 03045832 | Tappet Closing (#03045832) |
| 3 | 03053330 | Camshaft (#03053330) |
| 3 | 03053332 | EV CAMSHAFT MOD (#03053332) |
| 3 | 03053334 | Camshaft (#03053334) |
| 4 | 14234600 | PIN (#14234600) |
| 5 | 01054001 | Flange (#01054001) use 010540016 |
| 6 | 98084320 | Screw (#98084320) |
| 7 | 95120065 | WASHER (#95120065) |
| 8 | 01051700 | DRIVE WHEEL B (#01051700) |
| 9 | 01054500 | Drive Gear (#01054500) |
| 10 | 14433400 | WASHER (#14433400) |
| 11 | 92750180 | Nut (#92750180) |
| 12 | 14072001 | SPROCKET (#14072001) |
| 13 | 95100837 | WASHER (#95100837) |
| 14 | 92602525 | NUT (#92602525) |
| 15 | 91702355 | WOODRUFF KEY (#91702355) |
| 16 | 28058060 | TIMING CHAIN (#28058060) USE 05058030 |
| 17 | 30057810 | CHAIN TENSIONER (#30057810) |
| 18 | 98082435 | BOLT (#98082435) |
| 19 | 14615901 | WASHER (#14615901) |
| 20 | 03048230 | HYDRAULIC LIFTER (#03048230) |
| 21 | 03048330 | CALIBRATED PAD USE 973253500005 (#03048330) |
