2004 2007 Mgs 01 Corsa 1200 Connecting Rod Rear Shock Abs
| Position | Part Number | Description |
|---|---|---|
| 1 | 02550250 | Shock absorber (#02550250) |
| 2 | AP8150338 | Hex socket screw M12x108* (#AP8150338) |
| 3 | 02551550 | Spacer (#02551550) |
| 4 | 95008213 | Washer, 12.2x20x2 (#95008213) |
| 5 | 92660112 | NUT NYLOC (#92660112) |
| 6 | 02560850 | Hex screw M10 X 69 (#02560850) |
| 7 | 02560550 | RH Double conrod (#02560550) |
| 8 | 02551850 | Spacer (#02551850) |
| 9 | 02560650 | LH Double conrod (#02560650) |
| 10 | 02562150 | Nut M10 (#02562150) |
| 11 | 02562450 | Single conrod (#02562450) |
| 12 | 02562050 | Hex socket screw M10 X 135 (#02562050) |
| 13 | 95005328 | Washer 10,5x18x2 (#95005328) |
| 14 | AP8110068 | Oil seal D18x24x3 (#AP8110068) |
| 15 | AP8110066 | Needle bearing (#AP8110066) |
| 16 | AP8135608 | Double connecting rod pin (#AP8135608) |
| 17 | 91111050 | Spacer 10,2x25x50 (#91111050) |
| 18 | AP8121845 | Connect.rod pin (#AP8121845) |
| 19 | AP8152301 | Self-locking nut M10 (#AP8152301) |
| 20 | 95008210 | Washer (#95008210) |
| 21 | AP8157100 | Decal (#AP8157100) |
