2006 2007 Sport 1200 1200 Air Box
| Position | Part Number | Description |
|---|---|---|
| 1 | 05114031 | SCATOLA PORTAFILTRO COMPLETA (#05114031) |
| 2 | AP8104211 | AIR FILTER (#AP8104211) |
| 3 | 05113730 | Protection (#05113730) |
| 4 | AP8120615 | Gasket (#AP8120615) |
| 5 | 05103830 | Adhesive Sponge (#05103830) |
| 6 | 05113530 | Cover (#05113530) |
| 7 | AP8144164 | Intake hose (#AP8144164) |
| 8 | 05114130 | Air Box Support (#05114130) |
| 9 | AP8152329 | Self-Tap Screw (#AP8152329) |
| 10 | AP8152279 | Screw w/flange (#AP8152279) |
| 11 | AP8221023 | T Bush* (#AP8221023) |
| 12 | AP8120030 | Rubber Spacer (#AP8120030) |
| 13 | AP8150421 | Self-Tap Screw (#AP8150421) |
| 14 | 30729330 | AIR TEMP SENSOR (#30729330) |
| 15 | 30027931 | GASKET (#30027931) |
| 16 | AP8144038 | Fuel Pipe - Nevada (#AP8144038) |
| 17 | AP8101595 | Hose Clamp (#AP8101595) |
| 18 | AP8120876 | Plug (#AP8120876) |
| 19 | AP8120428 | Upper cable-guide (#AP8120428) |
| 20 | AP8152278 | #12 Screw w/ flange M6x16* (#AP8152278 ) |
