2006 2007 Sport 1200 1200 Rear Body Rear Fairing
| Position | Part Number | Description |
|---|---|---|
| 1 | 05573230 | Horn (#05573230) |
| 1 | 05573230Y01A | RH rear fairing, red (#05573230Y01A) |
| 1 | 05573230Y02 | RH rear fairing, black (#05573230Y02) |
| 2 | 05573330 | HORN LH (#05573330) |
| 2 | 05573330Y01A | LH rear fairing, red (#05573330Y01A) |
| 2 | 05573330Y02 | RH rear fairing, black (#05573330Y02) |
| 3 | AP8152339 | SCREW W/FLANGE (#AP8152339) |
| 4 | AP8102375 | Clip (#AP8102375) |
| 5 | 98682215 | Hex Socket Screw M5X15 (#98682215) |
| 6 | AP8152302 | SCREW W/ FLANGE (#AP8152302) USE 2B014101 |
| 7 | 05467330 | Hook (#05467330) |
| 8 | AP8152292 | Screw w/ flange M8x5 (#AP8152292) |
| 9 | ||
| 10 | 91120924 | Spacer 9X18X24 (#91120924) |
| 11 | 05464330NA | Handle. Black (#05464330NA) |
| 12 | 98682425 | Screw M8 X 25 (#98682425) |
| 13 | 05464830 | Cover (#05464830) |
| 14 | AP8152055 | Hex socket screw (#AP8152055) |
| 15 | AP8121096 | Disc cover bush (#AP8121096) |
| 16 | AP8120455 | Rubber spacer (#AP8120455) |
| 17 | 32944210 | GUARD DECAL (#32944210) |
