2007 2009 Bellagio 940 Rear Body Rear Fairing
| Position | Part Number | Description |
|---|---|---|
| 1 | 978340 | Rear tail blank (#978340) |
| 1 | 97834000EE | Rear fairing, grey/white (#97834000EE) |
| 1 | 97834000YR1 | Rear tail red/white (#97834000YR1) |
| 1 | 978340NG | Rear tail black (#978340NG) |
| 2 | AP8152339 | SCREW W/FLANGE (#AP8152339) |
| 3 | AP8102375 | Clip (#AP8102375) |
| 4 | 978336 | Splash guard (#978336) |
| 5 | 978335 | Number plate holder (#978335) |
| 6 | AP8134448 | Reflector Support (#AP8134448) |
| 7 | AP8152267 | Hex socket screw (#AP8152267) |
| 8 | AP8224164 | Rear Reflector, Red (#AP8224164) |
| 9 | AP8152306 | Self-Locking Nut (#AP8152306) |
| 10 | AP8150248 | Washer 5.5mm x 15mm x 1.6 mm (#AP8150248) |
| 11 | 978580 | Reinforcement Plate (#978580) |
