2008 2012 V7 Classic 750 Fuel Tank
| Position | Part Number | Description |
|---|---|---|
| 1 | ||
| 1 | 88346900BM | (#88346900BM) |
| 1 | 88346900Y02 | Fuel tank, black (#88346900Y02) |
| 1 | 88701900XR7 | Fuel tank red (#88701900XR7) |
| 1 | 887944 | Fuel tank (#887944) |
| 1 | 88798700Y02 | Fuel tank, black (#88798700Y02) |
| 1 | 978928 | RAW FUEL TANK (#978928) |
| 1 | 97892800BM | RAW FUEL TANK (#97892800BM) |
| 1 | 97892800Y02 | Fuel tank, black (#97892800Y02) |
| 1 | B06304700XR7 | Fuel tank, red (#B06304700XR7) |
| 2 | 883185 | Tank cap (#883185) |
| 2 | 883476 | Tank Cap (#883476) |
| 3 | 03101900 | GAS CAP FLANGE (#03101900) |
| 3 | 978929 | Gas Cap Flange (#978929) |
| 4 | 03103500 | SPACER (#03103500) |
| 4 | 883193 | SPACER (#883193) |
| 5 | 03101720 | RESTRICTOR 38MM (#03101720) |
| 6 | 03102200 | GAS CAP SEAT (#03102200) |
| 7 | 03101600 | GAS CAP GASKET (#03101600) |
| 8 | 03103200 | SCREW A (#03103200) |
| 8 | 825727 | Screw (#825727) |
| 9 | AP8152291 | Screw w/flange (#AP8152291) |
| 10 | 95005312 | Washer, 8.5x24x2 (#95005312) |
| 11 | 02107100 | TANK GROMMET (#02107100) |
| 11 | 91551131 | GROMMET (#91551131) |
| 12 | 883252 | SPACER (#883252) |
| 12 | AP8221128 | T. Bushing (#AP8221128) |
| 13 | AP8120965 | O-Ring (#AP8120965) |
| 14 | 30103730 | UNION (#30103730) |
| 15 | AP8101595 | Hose Clamp (#AP8101595) |
| 16 | 00823944050 | HOSE (#00823944050) |
| 17 | ||
| 18 | 03102400 | FLANGE GASKET (#03102400) |
