2008 Stelvio 1200 1200 Front Body Duct
| Position | Part Number | Description |
|---|---|---|
| 1 | 88307000BM | LEFT CYLINDER HEAD (#88307000BM) |
| 1 | 88307000Y01 | RIGHT FLANK ASSY red (#88307000Y01) |
| 1 | 88307000Y02 | RIGHT FLANK ASSY (#88307000Y02) |
| 2 | 978687 | SWITCH RH (#978687) |
| 3 | AP8150413 | Self-Tap Screw (#AP8150413) |
| 4 | 88307400Y10 | CONVOGLIATORE DX COMPLETO SILVERRIGHT DU (#88307400Y10) |
| 5 | 978431 | VANO PORTAOGGETTI (#978431) |
| 6 | 883140 | GLOVE COMPARTMENT GASKET (#883140) |
| 7 | 88307800BM | RIGHT COVER ASSY WHITE (#88307800BM) |
| 7 | 88307800Y01 | RIGHT COVER ASSY RED (#88307800Y01) |
| 7 | 88307800Y02 | RIGHT COVER ASSY BLACK (#88307800Y02) |
| 8 | 978641 | SHEET (#978641) |
| 9 | 978640 | FLANKS UNION (#978640) |
| 10 | 98710215 | SCREW (#98710215) |
| 11 | 01577830 | NYLON WASHER (#01577830) |
| 12 | 88307100BM | LEFT FLANK ASSY white (#88307100BM) |
| 12 | 88307100Y01 | LEFT FLANK ASSY red (#88307100Y01) |
| 12 | 88307100Y02 | LEFT FLANK ASSY BLACK (#88307100Y02) |
| 13 | 978688 | SWITCH LH (#978688) |
| 14 | 88307300Y10 | CONVOGLIATORE SX COMPLETO SILVERLEFT DUC (#88307300Y10) |
| 15 | AP8102375 | Clip (#AP8102375) |
| 16 | 978152 | RUBBER (#978152) |
| 17 | 91180600 | SPACER (#91180600) |
| 18 | AP8152302 | SCREW W/ FLANGE (#AP8152302) USE 2B014101 |
| 19 | 00823931055 | GASKET (#00823931055) |
| 20 | AP8117200 | Adhesive sponge (#AP8117200) |
| 21 | 98370412 | SCREW (#98370412) |
| 22 | AP8102381 | CLIP M4 (#AP8102381) |
| 23 | 463195 | Buffer for fairing fitting (#463195) |
| 24 | AP8144565 | WASHER (#AP8144565) |
| 25 | 883467 | RH CAP PAINTED (#883467) |
| 26 | 883468 | LH CAP PAINTED (#883468) |
