2008 Stelvio 1200 1200 Front Fork
| Position | Part Number | Description |
|---|---|---|
| 1 | 883678 | RH COMPLETE FRONT FORK (#883678) |
| 2 | 01530588 | Screw, 10mmx30mm (#01530588) |
| 3 | ||
| 4 | AP8150220 | Hex socket screw M6x30* (#AP8150220) |
| 5 | 981022 | Fork Tube RH (#981022) |
| 6 | 981023 | Bush (#981023) |
| 7 | 981029 | Fork Tube LH (#981029) |
| 8 | 981031 | Plunger, Complete RH (#981031) |
| 9 | 01530589 | Nut, 12mmx1.25 (#01530589) |
| 10 | 981032 | Plunger, Complete LH (#981032) |
| 11 | 978016 | FORK HEAD (#978016) |
| 12 | 66530505 | ALLEN BOLT (#66530505) USE 98682430 |
| 13 | 978018 | COMPLETE STEERING BASE (#978018) |
| 14 | 981045 | Sleeve plug RH (#981045) |
| 15 | 981028 | Sleeve plug LH (#981028) |
| 16 | 981024 | O-Ring (#981024) |
| 17 | 981025 | O-Ring (#981025) |
| 18 | 981026 | CIRCLIP (#981026) |
| 19 | 981027 | Circlip (#981027) |
| 20 | 981152 | Ring (#981152) |
| 21 | 981044 | Fork Sleeve (#981044) |
| 22 | 981033 | SPRING CAP (#981033) |
| 23 | 981034 | BUSH (#981034) |
| 24 | 981035 | Plunger (#981035) |
| 25 | 981036 | BUSH (#981036) |
| 26 | 981037 | Spring (#981037) |
| 27 | 981038 | Bush (#981038) |
| 28 | 981039 | Dust cover (#981039) |
| 29 | 981040 | Circlip (#981040) |
| 30 | 981041 | Gasket ring 50x63x11 (#981041) |
| 31 | 981042 | CAP (#981042) |
| 32 | 981043 | Bush (#981043) |
| 33 | 05781630 | Reflector, Amber (#05781630) |
| 34 | 883679 | LH COMPLETE FRONT FORK (#883679) |
