2009 2010 Stelvio 1200 NTX ABS 1200 Frame Rear Body I
| Position | Part Number | Description |
|---|---|---|
| - | 883618 | BATTERY FIXING PLATE (#883618) |
| - | ||
| - | ||
| - | ||
| 1 | 978446 | MUDGUARD FLAP (#978446) |
| 2 | ||
| 3 | ||
| 4 | 883024 | RH side panel, unpainted (#883024) |
| 5 | 883023 | LH side panel, unpainted (#883023) |
| 6 | 886206 | BAG SUPPORT RIGHT SIDE (#886206) |
| 7 | 886207 | BAG SUPPORT Left SIDE (#886207) |
| 8 | 883617 | BATTERY HOUSING (#883617) |
| 9 | ||
| 10 | ||
| 11 | 6704700 | Joint (#6704700) |
| 12 | ||
| 13 | ||
| 14 | 28576591 | CLIP (#28576591) |
| 15 | ||
| 16 | 98710215 | SCREW (#98710215) |
| 17 | 883177 | BOCCOLA 6.2X10X10.7 COL 13X1.5 (#883177) |
