2009 V7 Cafe 750 Frame Electrical System II
| Position | Part Number | Description |
|---|---|---|
| - | 49609601 | TIE STRAP (#49609601) |
| - | 977308 | ECU (#977308) |
| 1 | 883077 | Main Wiring Harness - Nevada (#883077) |
| 2 | 29729461 | OIL TEMP SENSOR (#29729461) |
| 3 | 03163330 | SENSOR HOLDER A (#03163330) |
| 4 | 95004210 | WASHER (#95004210) |
| 5 | 640201 | BATTERY 12V - 12Ah (#640201) |
| 6 | 32418210 | Clamp - Breva (#32418210) |
| 7 | ||
| 8 | ||
| 9 | 32517710 | Decal (#32517710) |
| 10 | 32747910 | Ground Lead - Breva (#32747910) |
| 11 | 883191 | Wiring - Breva (#883191) |
| 12 | 883161 | PLATE (#883161) |
| 13 | 98682212 | Hex Socket Screw (#98682212) |
| 14 | 95100059 | WASHER (#95100059) |
| 15 | ||
| 16 | 290860 | LAMELLAR FUSE 15A (#290860) |
| 17 | ||
| 18 | 28742562 | FUSE 30A (#28742562) |
| 19 | 883904 | ECU (#883904) |
| 21 | 95129101 | WASHER FUEL PUMP (#95129101) |
| 22 | ||
| 23 | ||
| 24 | 584509 | Fuel cut off/ tilt sensor (#584509) |
| 25 | ||
| 26 | 29732550 | RELAY (#29732550) |
| 27 | ||
| 28 | ||
| 29 | ||
| 30 | ||
| 31 | 30729330 | AIR TEMP SENSOR (#30729330) |
| 32 | 30027931 | GASKET (#30027931) |
| 33 | ||
| 34 | 14609650 | TIE WRAP (#14609650) |
