2009 V7 Cafe 750 Frame Fuel Vapour Recover System
| Position | Part Number | Description |
|---|---|---|
| 1 | ||
| 2 | ||
| 3 | 32439260 | Hose clamp (#32439260) |
| 4 | 95005311 | WASHER (#95005311) |
| 5 | ||
| 6 | 856063 | HOSE (#856063) |
| 7 | 856062 | HOSE (#856062) |
| 8 | ||
| 9 | 32115210 | Union - Nevada (#32115210) |
| 10 | 860138 | BLUE / ORANGE CANNISTER VALVE (#860138) |
| 11 | 856064 | Pipe (#856064) |
| 12 | 03658330 | FASCETTA LUNGA (#03658330) |
| 13 | 98257410 | Screw (#98257410) |
| 14 | 92630104 | NUT (#92630104) |
| 15 | 93301313 | BRACKET (#93301313) |
| 16 | ||
| 17 | ||
| 18 | 30103730 | UNION (#30103730) |
| 19 | 29108550 | HOSE CLAMP (#29108550) |
| 20 | 28157950 | BREATHER PIPE CLAMP (#28157950) |
| 21 | ||
| 22 | 00823923140 | THERMAL SHEATH (#00823923140) |
| 23 | ||
| 24 | 14609650 | TIE WRAP (#14609650) |
