2010 2013 Norge 1200 ie 8v Frame Foot Rests II
| Position | Part Number | Description |
|---|---|---|
| 1 | ||
| 2 | 98692430 | Hex Socket Screw M8X30 (#98692430) |
| 3 | 01576530 | Nut with Clip (#01576530) |
| 4 | 98692425 | Hex Socket Screw (#98692425) |
| 5 | 98680440 | Screw (#98680440) |
| 6 | ||
| 7 | 05446930 | Rh Protection (#05446930) |
| 8 | ||
| 9 | 05446431 | Ring (#05446431) |
| 10 | 98350210 | Screw (#98350210) |
| 11 | ||
| 12 | ||
| 13 | 05447430 | Lh Protection (#05447430) |
| 14 | ||
| 15 |
