2011 2013 Stelvio 1200 8v Std NTX Frame Handlebar Controls
| Position | Part Number | Description |
|---|---|---|
| - | 886159 | RH ELETTRICAL DEVICE (#886159) |
| 1 | 978040 | Handlebar (#978040) |
| 2 | 978821 | Holder (#978821) |
| 3 | 98700430 | BOLT FOR UPPER U BOLT GRISO 850/1100 (#98700430) |
| 4 | 978042 | RISER (#978042) |
| 5 | ||
| 6 | 886229 | LH lights selector (#886229) |
| 7 | ||
| 8 | ||
| 9 | ||
| 10 | 886234 | TAG (TERMINAL) (#886234) |
| 11 | 883543 | ELETTRICAL DEVICE (#883543) |
| 12 | 1603480 | #14 RH hand grip (#1603480) |
| 13 | ||
| 14 | ||
| 15 | 85222R | Gas trasmission delivery (#85222R) |
| 16 | 85223R | Gas trasmission return (#85223R) |
| 17 | 1609630 | #11 Hose clamp L46 mm (#1609630) |
| 18 | 978059 | SCREW (#978059) |
| 19 | 883460 | RH rearview mirror (#883460) |
| 20 | 883461 | LH rearview mirror (#883461) |
| 21 | 981101 | FRONT INDICATORS (#981101) |
| 22 | 981099 | FRONT INDICATORS LENS(#981099) |
| 23 | 981100 | FRONT INDICATORS (#981100) |
| 24 | 884312 | MIRROR MOUNTING STUD (# 884312) (#884312) |
