2011 2013 Stelvio 1200 8v Std NTX Headlight Horn
| Position | Part Number | Description |
|---|---|---|
| 1 | 887029 | Headlight (#887029) |
| 1 | 887820 | Front headlight assy (#887820) |
| 2 | 292723 | BULB 12V-55/60W (#292723) |
| 3 | ||
| 4 | 98680225 | Hex socket screw M5X25 (#98680225) |
| 5 | AP8221023 | T Bush* (#AP8221023) |
| 6 | AP8120030 | Rubber Spacer (#AP8120030) |
| 7 | 248419 | SPRING PLATE (#248419) |
| 8 | 978428 | TURN SIGNAL (#978428) |
| 9 | 584332 | LAMP - T/SIG. BULB - ORANGE (#584332) |
| 10 | 978427 | NORGE TURN SIGNAL (#978427) |
| 11 | 98682116 | Hex socket screw (#98682116) |
| 12 | 886325 | Horn (#886325) |
| 13 | AP8152279 | Screw w/flange (#AP8152279) |
| 14 | AP8152299 | Self-Locking Nut (#AP8152299) |
| 15 | 95129100 | WASHER (#95129100) |
| 16 | 91120507 | Bush (#91120507) |
| 17 | 95008205 | Washer 5.3mm (#95008205) |
| 18 | AP8102381 | CLIP M4 (#AP8102381) |
| 19 | 98680125 | Screw (#98680125) |
| 20 | 899522 | CABLE HARNESS (#899522) |
| 21 | 887821 | Oscuratore per proiettore (#887821) |
| 22 | 2R000006 | BULB SOCKET (#2R000006) |
