2012 2013 V7 Special Stone 750 Frame Electrical System II
| Position | Part Number | Description |
|---|---|---|
| - | 14609650 | TIE WRAP (#14609650) |
| - | 49609601 | TIE STRAP (#49609601) |
| 1 | 887825 | CABLE HARNESS (#887825) |
| 2 | 29729461 | OIL TEMP SENSOR (#29729461) |
| 3 | 3163330 | #35 Sensor support (#3163330) |
| 4 | 95004210 | WASHER (#95004210) |
| 5 | ||
| 6 | 638733 | Yuasa YTX14-BS (#638733) |
| 7 | 98370616 | BOLT (#98370616) |
| 8 | 32517710 | Decal (#32517710) |
| 9 | 32747910 | Ground Lead - Breva (#32747910) |
| 10 | 584211 | FUSE HOLDER TERM.BOARD 6 (#584211) |
| 11 | 883161 | PLATE (#883161) |
| 12 | 98682212 | Hex Socket Screw (#98682212) |
| 13 | 95100059 | WASHER (#95100059) |
| 14 | ||
| 15 | ||
| 16 | ||
| 17 | ||
| 18 | ||
| 19 | 893570 | PHONIC WHEEL SENSOR (#893570) |
| 20 | ||
| 21 | ||
| 22 | ||
| 23 | ||
| 24 | ||
| 25 | CM013202 | STOP CABLE/PIPE SPRING (#CM013202) |
| 26 | 894704 | Fairlead (#894704) |
| 27 |
