2012 2013 V7 Special Stone 750 Frame Rear Body I Mudguard
| Position | Part Number | Description |
|---|---|---|
| - | 978946 | REAR FENDER (#978946) |
| - | ||
| - | ||
| - | ||
| 1 | ||
| 2 | 978947 | REAR COVER (#978947) |
| 3 | ||
| 4 | 254485 | SPRING PLATE (M6) (#254485) |
| 5 | 98370831 | Screw (#98370831) |
| 6 | 91120806 | SPACER (#91120806) |
| 7 | 95005310 | WASHER (#95005310) |
| 8 | 92640708 | DADO IX NY M8X8,3 BASSO (#92640708) |
| 9 | ||
| 10 | 91180601 | Spacer (#91180601) |
| 11 | ||
| 12 | ||
| 13 | ||
| 14 |
